An Up Close Look at Master Korabel’s St. Gabriel Kit

One of the ship model kits that we started carrying last year is from the Russian ship model kit manufacturer Master Korabel. The kit, which doesn’t seem to get much attention, is called the St. Gabriel.

St-Gabriel_1s



For reasons I don’t understand, this ship is referred to as a “Deck Boat”. Perhaps it is a mistranslation from the original Russian description. In any case, this is actually a significant historical vessel. The Archangel Gabriel, or St. Gabriel, was one of three ships used by the Kamchatka Expedition of 1724 to 1731, and it was the main ship of the expedition’s leader, the Danish explorer and cartographer Vitus Bering, who was in the employ of the Russian Navy.

The expedition’s task was to explore the North Pacific coast of the Asian continent, and to determine whether or not it connected to the North American continent. For this task, the ship Archangel Gabriel, was built in Kamchatka in 1728 . According to a Wikipedia entry, the other ships of the expedition were used to ferry supplies from Okhotsk to Bolsheretsk, on the Kamchatka Peninsuala. For a more detailed description, the Wikipedia entry on Vitus Bering, is an interesting short read.

As for the model kit, Master Korabel’s created a lovely 1/72-scale model of the ship Archangel Gabriel. It’s a small model, owing to the manufacturer’s standardized scale, only 13.8″ long and 11.8″ tall.

Screen Shot 2021-03-28 at 6.14.08 PMScreen Shot 2021-03-28 at 6.14.23 PMScreen Shot 2021-03-28 at 6.14.36 PM

Note the photo-eteched brass hooks attached to the blocks. Master Korable makes beautiful blocks made from pear wood. They make blocks that actually look like real blocks.

As with other Master Korabel kits, the St. Gabriel kit features a specially engineered hull framing that is designed to prevent any distortion or twists in the hull shape. The hull is then double-planked and, most impressively, the finish planking is all laser-cut for you. This means that the planks aren’t just strips of wood that you need to shape in order to make them look neat and correct – it’s all been done for you. So, as long as you’re careful, you should end up with a perfectly planked hull.

Master Korabel’s St. Gabriel kit also features a laser-engraved deck that has all the planks and nail’s already marked on it. Together with the laser-cut hull planks, the kit is ideal for beginning ship modelers, or ship modelers who want a nice, accurate looking model, without spending all the time it might take to add all these extra details.

Deck is laser-engraved with all the planking and nail details.
The finish planks for the hull, laser cut to perfect shape.

We manage to find a very simple post of progress photos on the Model Ship World forum by a builder with the screen name Valentina. This one doesn’t describe any of the build process, but it includes photos of the kit contents, instructions, and so on. It even includes a few photos showing the construction of the optional ship’s boat (sold separately from the St. Gabriel kit). Click HERE to visit this build log.

We’ve also found a few nice nice Youtube videos. Here’s one that provides an overview of what’s in the kit. The narration is in Russian, but you can see the details of the kit:

There’s also a model builder by the name of Olya Batchvarov, who created a nice video presentation of the construction progress of her award-winning St. Gabriel model here.

For those interested in more of Olya’s work, check out her website, http://www.shipphotographer.com.

Note that this kit includes sail materials and the information for you to make your own sail. However, we also offer a set of pre-sewn sails, if you prefer not to do your own sewing. Also, the ship’s boat shown on the model is optional. It is Master Korabel’s MK0102 75mm ship’s boat kit.



So, if you’re interested in building your own model of Vitus Bering’s ship, check it out at Ages of Sal at: https://www.agesofsail.com/ecommerce/st.-gabriel-(master-korabel-1:72).html

Ω

Vanguard Models Shipment Received

After a long hold up by the shipping company, we finally received our shipment from Chris Watton’s Vanguard Models company in England!

Vanguard Models, as you may already know, is one of the newest ship model manufacturers on the market, and already they make some of the finest kits available. Their kits are popular, interesting, and challenging. But, Chris has gone out of his way to make the kits as easy to build as possible, providing clear instructions in english, and advanced engineering, using computer aided design to come up with ways to simplify construction.

HMS Speedy

HMS Speedy, shown above, is a model of a 14-gun British Royal Navy brig. We ran out of stock of these following the holidays, so we’re happy to announce that they’re back in stock, and ready to ship to you!

There are four other ship model kits available from Vanguard Models besides HMS Speedy: HMS Flirt, HMS Alert, the Royal Yacht ‘Duchess of Kingston’, the Scottish Zulu ‘Lady Isabella’ and the Scottish Fifie ‘Lady Eleanor’.

HMS Flirt

HMS Alert

Duchess of Kingston

Scottish Zulu ‘Lady Isabella’

Scottish Fifie ‘Lady Eleanor’

Detailed instructions are provided in english, with lots of photos to help you through every step of the build. Below is a sample of one page from the Duchess of Kingston kit’s 80-page instruction set.

Want to see more from the instructions? Download the whole set in pdf format here.

Check out all five of these wonderful kits from Vanguard Models, in stock now, at Ages of Sail: https://www.agesofsail.com/ecommerce/new-vanguard-models.html



A Billing Boats Roar Ege Viking Ship Model

Recently, some photos were posted in the builder’s gallery of the Nautical Research Guild’s Model Ship World forum. The model caught our attention as it was a perfectly done model built from Billing Boats’ Roar Ege Viking Ship kit.

Roar Ege model by Jens Kronvold Frederiksen

The model was built by Jens Kronvold Frederiksen, who goes by his screen name kronvold on Model Ship World. If you look closely at the photos, this is a perfect example of how it’s done, though Jens may humbly disagree.

Of course, each person adds his or her own style to a build, but this is a very clean build, and it shows off the details of the model really well.

We hope this provides some inspiration to our readers. We couldn’t help but post a lot of photos of this model, but there are more in Jens’s album on MSW. They are also higher resolution than we typically post here, so you might want to check them out: https://modelshipworld.com/gallery/album/2288-roar-ege-billing-boats/

If you have any interest in building this model yourself, it is in stock at Ages of Sail and selling for $132. Check it out here: https://www.agesofsail.com/ecommerce/roar-ege-viking-ship—billing-boats-bb703.html

Ages of Sail



Building the Amati “Arrow” Gunboat

Here’s an interesting post about building Amati’s Arrow Gunboat, a popular kit here at Ages of Sail.

The kit is an attractive model that doesn’t take up too much room at about 18-1/2″ long and about 11″ high, not including the launch ways style display stand that’s included in the kit. The kit lists for $108.99, and if you’re interested in building one for yourself, you can find in on our online shop here:

https://www.agesofsail.com/ecommerce/am1422-amati-arrow.html

Ship Modeler

Amati Model of Italy makes a wide variety of interesting ship modelings subjects. In early 2018, I finished building their Swedish Gunboat kit. Like that one, another gunboat that has been around for as long as I can remember, and was always intrigued by, is the “Arrow” an American Gunboat from the period around the War of 1812.

The Jeffersonian era was an interesting time in American naval history in the desire to use defensive gunboats in place of large expensive warships. As a result, there were numerous gunboat designs implemented. In Howard Chapelle’s book, The History of the American Sailing Navy, several of these designs can be found. Among them is a design that Chapelle describes as a “galley gunboat showing Mediterranean influence.” Clearly, this was the drawing that inspired the Arrow gunboat kit.

View original post 1,244 more words

War of 1812 Gunboats

On shipmodeler.wordpress.com is some discussion about American gunboats and Amati’s Arrow Gunboat kit. This is a popular kit for its detail, appearance, and unusual subject matter. Plus, it has a simple rig, making it a fun and quicker build than many more complicated ship model kits.

If you want to try building this kit for yourself, you can find here: https://www.agesofsail.com/ecommerce/am1422-amati-arrow.html

Ship Modeler

So, this past week, I’ve been having a few conversations with Mr. Paul Reck, who’s an accomplished ship modeler that runs the Hyde Street Pier Model Shipwrights club in San Francisco. I’ve been a member of that group for at least 10 or 11 years. Paul has been talking for some time about gunboats of the Jeffersonian navy. So, 1801 through the War of 1812. And, yes, that’s technically into the Madison presidency, but we’re talking about the gunboat navy that took shape under Jefferson.

Paul has built a model of the War of Independence gunboat Philadelphia and small galley cutter Lee. Lately, his attention turned to these Jeffersonian gunboats. This is something I’ve always had an interest in, though my knowledge doesn’t really go past a couple historical books on the War of 1812 and the Barbary Wars, and Howard Chapelle’s book History of the American Sailing Navy.

A…

View original post 533 more words

New Kit Sneak Peek: Shackleton’s ship Endurance

Just found out today that OcCre has produced another new kit, which they announced on their Facebook page today. The kit is a 1:70-scale model of the ship Endurance, which carried Sir Ernest Shackleton and his crew on their famous Trans-Antarctic Imperial Expedition in 1914.

The Endurance was a 3-masted barquentine or barkentine that was first built in Norway as the Polaris and renamed the Endurance by Shackleton when it was purchased for the expedition. The 144 foot long ship is described as one of the most heavily built wooden hulled ships in the world, designed to withstand the crushing pressure of operating in ice flows.

Continue reading

Taking Another Look: Greek Galliot from Amati Model

One small gem of a kit that often gets overlooked is Amati’s Greek Galliot. It’s probably because the average person looks at it, but doesn’t really know what to make of it. It looks mediterranean, a bit exotic, but what is it? What is a galliot?

The term was applied to a few different types of ship, but the Mediterranean galliot was a small lateen rigged shipped that also regularly used oars for propulsion. These ships were used by, among others, the Barbary pirates that operated out of North Africa. But, these ships were also used by the Greeks in their fight for independence against the Ottoman Turks between 1821 and 1829.

Amati’s Greek Galliot kit depicts a ship operating as a Greek privateer during the time of the War of Greek Independence. The ship is equipped with three lateen-rigged masts and a single bank of 12 oars on each side. Armament consists of a pair of bow mounted carriage guns, and swivel guns lining the quarterdeck.

At a scale of 1:65, this kit builds into a model 21.7″ long, about 55cm. The rig of this kind of ship is relatively simple, but the kit offers plenty of details, plus a couple cannons and an unusual ship design to make the build interesting.

Provided planking includes beech wood, walnut, and beautifully exotic red padauk wood for planking the inner bulwarks.

If you notice the fancy decorative inlaid wood pattern in the photos above and below. Amati includes a strip of this pre-made wood. The inlay pattern actually varies between kits, so your own model will likely be different from these. The kit also includes sailcloth pre-printed in color.

Even the instructions tell you that the oars would be in place only when the sails are clewed up. So, they didn’t follow their own instructions for the model in these photos, but the model sure looks nice displayed this way. And, to finish up your model display, this kit even includes the walnut stanchions and a beautiful wooden base, though the one in the currents kits are oval and not rectangular as shown in these photos.

The Greek Galliot is currently listing on our online store, Ages of Sail. for $124.95. This is a really interesting subject and as you can see here, it’s a gem of a model. You can order your’s today right here. Remember, as an Amati distributor, we offer free parts replacement on any Amati kit you buy from us. So, break or lose a part? Don’t worry. We have you covered.

Check out our huge inventory of ship model kits, fittings, tools, and accessories at Agesofsail.com

Ω



Taking Another Look: Arrow Gunboat from Amati Model

A very interesting kit that has been available on the market for quite some time is a wooden model kit that is not really a ship, but an American gunboat from the early 1800s. It is Jeffersonian-era gunboat.

During this time, the United States had limited resources to protect it’s vast coastline, and there was a lot of debate over the necessity and usefulness of a sea-going navy. As war loomed, the country invested in large numbers of gunboats – small war boats that were lightly armed, and could be powered by sail or oar. The boats made for small targets and were extremely maneuverable and could operate in waters too shallow for larger sailing ships.

There were many gunboats built and many designs appeared. Generally, they were shallow draught, had a simple rig, and carried one or two medium-sized carriage guns or carronades. Unique innovations appeared, with some mounting two guns facing opposite directions on a single circular turntable, so that after one cannon fired, the whole turntable was rotated to bring the second cannon to bear on the target while the other was reloaded.

One design featured a long and narrow hull with a gun at each end, each on its own pivot mount. The vessel showed a mediterranean influence with the use of a pair of lateen sails, each on separate masts. This particular design became the subject of Amati’s “Arrow” Gunboat kit. Here we take another look at this popular Amait kit.

Amati’s “Arrow” is a 1:55-scale wooden model kit of one of these gunboat designs. The specific design can be find in the book The History of the American Sailing Navy, by Howard I Chapelle. By the way, though long out of print, this is an interesting book and a good reference, and used copies in good condition can easily be had for about $10.

41ZJX903RPL

Amati’s kit measures kit measures about 18.5″ long and features a double-planked hull on a framework of laser-cut bulkheads. Bronzed metal barrels are included for one long gun and one carronade. Printed sailcloth is included for the two lateen sails. Three sheets of plans are included, as is a step-by-step instruction guide. The instruction guide is printed in Italian, but an insert includes all the text in english.

This kit makes for an interesting build of a unique type of craft that formed an important part of American history. The completed model’s graceful lines are certain to draw attention. The model is ideal for those who want to build something attractive that doesn’t require as much time as it takes to build a square rigger or any of the larger warships with their rows of gunports and cannons. But, with the large, detailed long gun and carronade in their swivel mounts,  it carries just enough armament to make it stand out.

There is enough challenge here, and a surprising amount of rigging for a small vessel with only two lateen sails. This model kit sells for $108.99 and includes a launch ways style base.

Order yours today at Ages of Sail here.

For some interesting info on one of the Jeffersonian gunboats, check out this Wikipedia entry on HMS Ambush here. HMS Ambush was formerly American Gunboat No. 5, captured by the British in 1814 during the Battle of Lake Burgoyne.

Ω

The Quartermaster Vignette

For those of you who don’t really have time for a full-on ship model project, or maybe just want something small and self-contained that’s ship model related, here’s a little-known product that we’ve had for some time here at Ages of Sail. This is The Quartermaster from Flagship Models.

This 1:32 scale mini-diorama is a resin kit with real wood planking for the deck. This is a pretty easy build that requires painting, including the Quartermaster figure himself.

The diorama is based on the Quarterdeck of a real ship, the British heavy frigate HMS Diana. The Diana was a 38-gun frigate of the Artois class, launched in 1794.

This kit normally sells for $60, but our website hasn’t been updated at the time of this writing. So, if you hurry, you can get it for only $50 here on Ages of Sail: https://www.agesofsail.com/ecommerce/the-quartermaster-(flagship,-1:32).html

Of course, if you prefer to build a whole ship model, we have two different HMS Diana kits available, a 1/85-scale kit from OcCre and a 1/64-scale kit from Caldercraft.

Here’s the link for the OcCre kit: https://www.agesofsail.com/ecommerce/diana.html

And the link for the Caldercraft kit: https://www.agesofsail.com/ecommerce/caldercraft-diana.html

Ω

New Kits from Türkmodel Now in Stock

Türkmodel, or Turk Model as we have them listed, is a major manufacturer of wooden ship model kits based in Turkey. For the past several years, the company has engaged in the production of wooden model ship and boat kits using computer aided design technology to their create model kits. They have been producing kits under their own label, as well as kits for regional companies like Nordic Class Boats, Modell-Tec, and others.

Turk Model’s line up of ship and boat model kits includes fishing boats, passenger ferries, various workboats, recreational sail boats and speed boats, and then some. One example is the Swedish passenger ship Bohuslän, produced for Nordic Class Boats. This kit is a big 1/45-scale model that now includes an LED lighting set. The model is designed so that it can be converted to R/C operation, though it makes a beautiful display model.



At Ages of Sail, we’ve just expanded our inventory by introducing 10 new Turk Model kits. To read more about the model kit or to order one, simply click on the linked images below.



Killing Sailboat



Astraal Fishing Boat



M/S Finnmarken



FPV Westra



Kubra Retro Speed Boat



Taka, Black Sea Fishing Boat



Skibladner Paddle Steamer



Jeanett Nordic Fishing Boat



Oselvar Faering



Conny Nordic Fishing Boat



You can also browse the full line of Turk Model kits that we carry at Ages of Sail here: https://www.agesofsail.com/ecommerce/turk-model.html
